the top selling recreational marine Hydraulic cylinder for Outboard powered boats from the leader in marine steering technology, SeaStar Solutions (formerly teleflex marine). the HC5345-3 front mount Outboard steering cylinder offers excellent resistance to repeated compression set and is designed to better withstand the harsh marine environment. It also features independent engine tilt for twin/Triple engine installations and varying lock-to-lock turn ration dependent on helm selection. The new end gland Sealing system has been redesigned with an 8-hole design for improved serviceability and updated with position able stainless steel O-ring (orb) fittings for easy Hose routing. the HC5345-3 meets ABYC and NMMA Certification standards and is designed and manufactured in North America. The cylinder is also compatible with SeaStar power assist pump (pa1200-2) which provides an automotive feel to driving your boat with fingertip control. the HC5345-3 steering cylinder is ideal for cruisers, runabouts, center console boats, offshore fishing boats and many more. upgrade options to consider: • stainless steel bulkhead Hose fittings • tilt steering • SeaStar power assisted steering SeaStar products are backed by a two-year recreational user warranty against manufacturing defects. SeaStar Hydraulic steering systems are tested and certified using only SeaStar Hydraulic fluid and SeaStar Hydraulic hoses. Use of non-certified products to install SeaStar products may VOID warranty and could cause loss of steering control.

Not recommended for boats that exceed 75 mph or run surface piercing props or the power exceeds the maximum Coast Guard rating for the vessel. 8.34 cubic inches in volume capacity. Independent engine tilt for twin/triple engine installations. State of the Art Proprietary Sealing System offers superior resistance to repeated compression set and is designed to better withstand the harsh environment. Positionable Stainless Steel O-Ring (ORB) Fittings for easy hose routing. Robust Barrel design and NEW graphics compliment new boats and motor packages. Built and certified to meet safety & quality requirements established by the American Boat & Yacht Council (ABYC) and International Standards Organization (ISO).

Mounting Type: Engine. Recommended Uses For Product: For Fishing Boats. Material: Plastic. Color: One. Item Weight: 9.03 Pounds. Brand: Dometic SeaStar. Date First Available: December 3, 2014. Best Sellers Rank: #153,152 in Sports & Outdoors. Customer Reviews: 4.9 out of 5 stars 107 ratings 4.9 out of 5 stars. : B00QJ6T9PQ. Included Components: ?O/B FM PP Cylinder. Part Number: ?HC5345-3. Manufacturer: ?SeaStar. Number of Items: ?1. Suggested Users: ?Unisex-adult. Material: ?Plastic. Color: ?One. Model Name: ?O/B FM PP Cylinder. Warranty Description: ?Limited warranty. Country of Origin: ?Canada. Brand Name: ?Dometic SeaStar. Item Weight: ?9.03 Pounds. Item Dimensions LxWxH: ?22.7 x 5.2 x 3.7 inches. Package Weight: ?4.4 Kilograms. Item Package Dimensions L x W x H: ?24 x 5 x 5 inches.
